Infrared video magnifier Genetika-LTV
Infrared (IR)video magnifier"Genetics-LTV" intended forlight-opticalexamination of sheet dielectric materials, including documents such as: passport, driver's license, identity card, transport and travel documents, exit visas and stamps, banknotes and banknotes, other securities and other documents with symbolic information and special protection, in the infrared range of the electromagnetic radiation spectrum.
This device helps to control objects in reflected and luminescent IR radiation using 2-band upper andobliqueIR illuminators, as well as a blue-green illuminator with the output of control results on an LCD monitor.
A special feature of the product is that it can connect to both the “Genetics 02-02” forensic unit and the “Genetics 09” universal detector, and is also capable of operating as a stand-alone device.
Video magnifierCan connect to standard monitors with analog input and 12V DC power.
The highly sensitive video camera built into the device is designed and adapted specifically for working in infrared modes.
Optical design implemented invideo loop"Genetics LTV" creates uniform illumination of the test object, which increases reliability of the test.
Note: the emission range of IR LEDs lies in the range of 800 – 950 nm with wavelengths of illuminators λ1<λ2<λ3.
Performance characteristics (TTX) of the Genetika-LTV video magnifier:
| Emission power of IR LEDs of each spectral range | More than 16 mW (at 100 mA current) |
| Brightness of NW LED | More than 2.5 cd (at 20 mA current) |
| Operating spectral range of a television channel | Min 700 nm Max 1000 nm |
| Dimensions of the television channel observation field | 24x36 mm |
| Wavelengths of the upper IR illuminator of the video magnifier: · IK-1 · IK-2 |
· 830 nm · 940 nm |
| Wavelength of oblique IR illuminator | 950 nm |
| Wavelength of blue-green (BG) video lens illuminator | 505 nm |
| Power supply | from the “GENETIKA-02” device, or another source with a constant voltage of 12 V |
| Video signal standard | PAL |
| Video magnifier power consumption | Up to 700 VA |
| LCD monitor power consumption | Up to 500 VA |
| Operating temperature range | Min +10°С Max +35°С |
| Dimensions: · video loops · liquid crystal display (LCD) monitor with cable · carriage with tripod (in storage position) |
· 127x73x60 mm · 150x27x136 mm · 120x75x80 mm |
| Weight: · video loops · LCD monitor with cable · carriages with tripod |
· 0.25 kg · 0.40 kg · 0.20 kg |
