X-ray television installation (introscope) Rapiscan 628DV
X-ray television installation "Rapiscan628D.V.»
RTU Rapiscan 628DV is a popular X-ray television installation for inspection and control of large cargo at airports, customs checkpoints, as well as checkpoints of specially protected facilities. The “Rapiscan 628DV” installation, thanks to a 1000 mm x 1000 mm tunnel and the use of 2 x-ray tubes, has the ability to construct a two-angle image, which eliminates the need for additional scanning of a suspicious object in another plane.
The device is indispensable when monitoring large-sized cargo arriving at a facility, which cannot be inspected using systems designed to control hand luggage and baggage. The “Rapiscan 628DV” introscope is a two-projection RTU with a low-lying conveyor belt, which is often necessary for the customer, since the upper location of the tunnel would make the use of the introscope impossible. Exclusive developments in diode lines and image recognition algorithms are used, which provide maximum levels of detection of dangerous objects and separation of materials.
The system can also be equipped with the TARGET function, which allows you to automatically recognize potentially dangerous objects if their characteristics match those corresponding to explosives or drugs. Like all X-ray television units of the 600 series, the model is mounted on a standard platform, which simplifies maintenance and operation. The Rapiscan 628DV installation has a dual-energy imaging function, the introscope has a streamlined ergonomic design, and is equipped with the multifunctional Rapiscan OS600 software.
Performance and Technical Characteristics: Rapiscan 628DV
| Tunnel size, mm | 1000 x 1000 |
| Overall dimensions of the installation | 4360 x 2199 x 2026 |
| Load capacity, kg | 165 |
| Operating temperature range, C | From 0 to +40 (in difficult climatic conditions it is possible to install additional cooling systems to avoid overheating) |
| Conveyor speed, m/s | 0.22 |
| Installation weight, kg | 1772 |
| Ready to work time, sec | 10 |
| Work cycle | around the clock |
| Penetration on steel, mm | 35 (guaranteed) / 38 (standard) |
| Resolution, mm | 38 (standard) / 40 (guaranteed) |
| X-ray tube, voltage | 160kV (180kV option available with 42mm steel penetration) |
