X-ray television installation (introscope) Rapiscan 632DV
Rapiscan 632DV –two-projection X-ray television system with tunnel dimensions of 1537 mm (width) by 1650 mm (height), having a durable roller conveyor for heavy loads, designed for inspection of pallets and large loads weighing up to 3000 kg.
The image created by the Rapiscan 632DV introscope in two perpendicular projections allows you to get a more complete picture of the contents of the scanned object, regardless of its orientation in the X-ray system.
Like other 600 Series X-ray systems, the Rapiscan 632DV is mounted on a standard platform, making it much easier to operate and maintain.
The inspection installation meets the most serious global safety requirements: ACSTL, STAC, TC.
Software – Rapiscan 0S600.This feature-rich software features an intuitive graphical user interface, improved picture quality and enhanced LAN connectivity.
Introscope uses more than thirteen image processing tools and algorithms to effectively detect hidden threats, namely the following options:
- – TIP – a program that introduces a digital projection of a dangerous object into the image of luggage with a programmable frequency;
- – TIPNET – a secure high-speed network connecting the network of all projections of a dangerous object with the central station;
- – Target—identification of a potentially dangerous item through analysis of mass, size and atomic number;
- – DTA – generates an alarm when the density of the displayed object exceeds the user-defined one.
There is also the opportunity to receive training on basic functions and capabilities in the user-friendly OTP application - Operator Training Program.
Standard features:
- – multi-energy image construction (4 colors);
- – view previous/next baggage;
- – archive of images;
- – конфигурируемые клавиши обработки изображения;
- – luggage counter;
- – date/time display;
- – search indicator;
- – flat LCD monitor;
- – uninterruptible power supply;
- – multilingual support.
Standard image processing functions:
- – Crystal Clear function;
- – viewing in black and white mode;
- – highlighting the contours of objects;
- – variable color division;
- – adjustable gamma;
- – separation of organic/inorganic materials;
- – inverse image;
- – high penetration;
- – variable color selection;
- – variable separation of materials with different densities;
- – continuous dynamic zoom and panning;
- – scaling (up to 64x).
Specifications: Rapiscan 632DV
| Dimensions: | Length: 7788 mm
Height: 3331 mm Width: 2816 mm |
| Tunnel dimensions: | 1537 mm (Width) x 1650 mm (Height) |
| Conveyor speed: | 0.20 m/s |
| Maximum load: | 3000 kg, evenly distributed |
| Conveyor height: | 345 mm |
| Weight: | 4823 kg |
| Bandwidth: | 600-700 units/h |
| Nutrition: | 115/230 V for 60/50 Hz |
| Steel penetration: | Guaranteed: 45 mm
Standard: 50 mm |
| Material separation: | Low Z, medium Z, high Z with an accuracy of 0.5 Z, where Z is the atomic number |
| Generator cooling: | Sealed oil bath with forced ventilation |
| Generator anode voltage: | 160 kV |
| Generator tube current: | 1.0 mA |
| Generator orientation: | Vertical down and horizontal |
| Protection class: | IP 20 – system;
IP 43 – operator control panel; |
| Storage temperature: | From -20 to 50°C |
| Operating temperature: | From 0 to 40°C |
| Relative Humidity: | 5-95% without condensation |
