LowCam VI104 vehicle underbody inspection system
The LowCam VI104 vehicle underbody inspection system is a stationary system for vehicle underbody inspection from Advanced Detection Technology.
Eight high-definition color cameras with motion sensors automatically start the process of checking the underbody of the vehicle. All information is displayed on a 21” operator monitor in four projections.
“LowCam VI104” has a low profile, only 25 centimeters, which reduces installation time and cost.
The housing design is made of high-strength materials, can withstand heavy loads, and also reliably protects the electronics from any atmospheric influences.
Optional:
– Recognition of state registration plates
– Extended cable (for placing workstations over 100 m.)
– Additional storage for archiving recordings
– Larger diagonal monitor
Performance characteristics (TTX): Car underbody inspection system LowCam VI104
| Transport speed | up to 15 km/h |
| Maximum load on the scanning module | up to 18 tons |
| Backlight | Ultra-bright LED |
| Remoteness of the workstation operator | < 100 m |
| Number of stored videos | 100,000 hours |
| IP degree of protection | 67 |
| Scanning module operating temperature | -34℃ to +60℃ |
| Control module operating temperature | from 0℃ to + 40℃ |
