LowCam VI108 vehicle underbody inspection system
The Lowcam VI 108 device is popular among vehicle underbody inspection systems, as it has various additional options, is convenient to use, and weighs little. It is easy to move from place to place without additional assistance.
Design
The device is equipped with eight built-in cameras with color video recording. Using the navigation buttons, the device operator can change the basic parameters of video transmission - rewind, zoom, flip through images, pause.
For operation, special software is used, which is included in the kit. The i5 Intel processor is used for operation, the built-in memory is 500 GB, this volume is enough to save and record 75,000 images.
The aluminum case protects the device from accidental damage, it is not subject to corrosion and wear. The weight of the device is only 16 kg. The entire kit is housed in two compact and durable Pelican cases.
Functionality
The vehicle underbody inspection system starts scanning automatically. The operator receives the image on the display in real time and can immediately control it.
Features of the vehicle underbody inspection system “Lowcam VI 108”
- transmission of images and videos in real time;
- compact dimensions;
- built-in memory and processor for data processing.
Performance characteristics (TTX): Car underbody inspection system LowCam VI108
| Monitor Specifications | Touchscreen 21“ 1920x1080 pixels, with protection against solar glare |
| Transport speed | up to 15 km/h |
| System deployment time | up to 180 sec. |
| Maximum load on the scanning module | up to 20 tons |
| Backlight | Ultra-bright LED |
| Remoteness of the workstation operator | up to 100 m |
| Number of stored videos | more than 75,000 |
| IP degree of protection | 67 |
| Scanning module operating temperature | -34℃ to +60℃ |
| Control module operating temperature | from 0℃ to + 40℃ |
| Total weight of the set | 68.4 kg. |
