LowCam VI54 vehicle underbody inspection system
This is a compact and lightweight vehicle underbody inspection solution from Advanced Detection Technology.
Deployment time by one person is less than 60 seconds.
The scanning module with two cameras is made of aircraft aluminum, weighs no more than 3.5 kilograms and can withstand a load of up to 18 tons.
The vehicle underbody inspection complex transmits video from high-resolution color cameras in real time and displays the image on the operator’s screen in two projections.
The LowCam VI54 system is suitable for field operations, as well as for inspection operations of vehicle undersides at temporary perimeters.
The entire kit is housed in a compact and durable Pelican 1510 case.
Performance characteristics (TTX): Car underbody inspection system LowCam VI54
| Image Resolution | 1366*768 pixels on a 15.6“ diagonal monitor |
| Transport speed | up to 16 km/h |
| System deployment time | < 60 s |
| Maximum load on the scanning module | up to 18 tons |
| Backlight | Ultra-bright LED |
| Remoteness of the workstation operator | < 100 m |
| Number of stored videos | 250 |
| IP degree of protection | 67 |
| Scanning module operating temperature | -34℃ to +60℃ |
| Control module operating temperature | from 0℃ to + 40℃ |
| Scanning module size | no more than 320x270x80 mm (WxLxH) |
| Scanning module weight | < 3.5 kg |
| Total weight of the set | no more than 18 kg |
