Stationary metal detector monopanel RADARPLUS MONO 01
Stationary monopanel metal detectors made in RussiaRADARPLUS, designed to quickly and accurately detect metal objects on the body.
Advantages of Model Mono 01:
- 6 detection zoneson the one hand, detailed zoning to accurately determine the location of the metal;
- Passage width up to 700 mm— suitable for most categories of visitors;
- Intelligent Sensitivity Adjustment— from 100 to 999 levels;
- High detection accuracyno false alarms from keys, coins and buckles;
- Light and sound alarm— instant reaction in case of threat;
- Temperature range: from -20 to +55°C— operation in a wide climatic range;
- Integration with access control system— the ability to automatically interact with turnstiles and doors;
How to use:
- Install the metal detector indoors taking into account the recommended operating conditions.
- Connect the power, adjust the sensitivity taking into account the object’s tasks.
- Provide control of the device - through the panel, remote control or RADARPLUS software.
- If necessary, connect the device to the access control system or use dry contacts to automate scenarios (for example, blocking a turnstile during an alarm).
- When an alarm is triggered, the system gives a light and sound signal - the operator takes action.
Why do you need this:
RADARPLUS MONO 01- an ideal choice for controlled access facilities where high inspection accuracy and minimization of inspection time are required:
- State authorities
- Educational institutions
- Medical organizations
- Airports and train stations
- Cultural and sports grounds
- Enterprises with access control regime
With high detection accuracy, intelligent configuration and integration capabilities, this model effectively copes with security tasks in a wide range of areas.
| Specifications | ||
| Working detection width | up to 700 mm | |
| Detection zones | 6 zones (one way) | |
| Color | standard gray (or upon request according to RAL) | |
| Temperature | -20 to +55 °C | |
| Degree of protection | IP20 | |
| Bandwidth | up to 60 people/min | |
| Alarm type | sound + light | |
| Installation location | room | |
| Operating frequency | ≥ 4 KHz, ≤ 8 KHz | |
Equipment:
- Metal detector RADARPLUS MONO 01
- Power cable
- Operating instructions
On request:
- Touch control with Russian-language interface
- Remote control
- Thermometry module (body temperature measurement)
- Two-way pass counter
- Ethernet/Wi-Fi module
- RADARPLUS software
- Dry contacts for integration with turnstiles
- Waterproof housing IP65
- Built-in battery for battery life up to 6 hours
