Integrated inspection complex SmartScan IntelliMax (IntelliMax)
Description
Integrated inspection complex SmartScan IntelliMax - a comprehensive security control system
The integrated inspection complex SmartScan IntelliMax is a modern solution for ensuring security at facilities with a high flow of visitors. The complex combines several inspection technologies and allows you to effectively detect weapons, explosives and other prohibited items.
The system is used at transport hubs, airports, train stations, administrative buildings and industrial enterprises. It provides multi-level screening of people, carry-on luggage and baggage, helping security teams quickly identify potential threats.
The complex is suitable for transport infrastructure facilities, sensitive areas and crowded places. SmartScan IntelliMax helps you achieve efficient screening and improve security without sacrificing throughput.
A revolutionary development in the field of security, the SmartScan IntelliMax complex combines two critical monitoring functions. Thanks to its compact design, the device simultaneously detects metal objects and monitors background radiation, saving space in the inspection area.
The system is equipped with an information screen that clearly demonstrates the location of detected metal objects, the intensity of signals from metal and radioactive sources. The complex effectively detects various types of weapons and instruments, and prevents the transportation of dangerous radioactive and nuclear materials.
Integration with centralized information processing systems and a universal interface significantly simplify the work of staff. This innovative solution allows for comprehensive screening at one point, greatly simplifying security controls.
In accordance with the norms of Russian legislation, in particular Government Decree No. 969 of September 26, 2016, the SmartScan IntelliMax integrated inspection system, created by domestic developers, has successfully passed certification tests. The document regulates the mandatory certification and functional characteristics of equipment that ensures safety at transport facilities, which allows the use of this system at various transport infrastructure facilities.
Tactical and Technical Characteristics (TTX):
| Name | Characteristic |
| Number of detection zones | 18 |
| Degree of object localization | Accurate |
| Bandwidth | 60 people/min |
| Sensitivity Setting | 1…100%, in 1% steps |
| Independent sensitivity adjustment in 6 horizontal levels | Yes, ±99% relative to base |
| Independent adjustment of panel sensitivity | Yes, in each level separately, ±99% |
| Number of selective detection programs | 22 |
| Nutrition | ~88…264V, 47…63Hz, 50W |
| Operation from built-in uninterruptible power supply | up to 40 hours (additional option) |
| Operating temperature range | -20…+55C |
| Relative humidity | up to 95%, no condensation |
| Passage dimensions | 2032 x 762x410 mm |
| Dimensions | 2210 x 840 x 410 mm |
| Weight | 63kg |
| Overall dimensions of the central unit packaging | 810 x 440 x 210 mm |
| Overall dimensions of the side panels packaging | 2290 x 470 x 160 mm |
| Package weight | 67kg |
 Detection zones |
 Standard programs |
 User programs |
 When installed in a row |
 Operating temperature |
 Visitor counter |
 Registry 878 |
 Digital frequency synthesis |
 Protocol |
 Radiation control |
 Certificate 969 |
 Remote monitor |
