ADK PRISMA-M– diagnostic complex for measuring the mass fraction of chemical elements in:
- working oils and liquids;
- drinking, natural and waste waters;
- soils;
- in the air of the working area and in gas and dust flows after deposition on the filter;
- metals and alloys
in accordance with certified (standardized) measurement methods (when used in the field of state regulation to ensure the uniformity of measurements).
The analyzer is operated by one person and operates in stationary and mobile diagnostic laboratories.
Identifies up to 80 chemical elements from sodium Na (Z=11) to americium Am (Z=95).ADK PRISMA-Mequipped with a rotation device with the ability to adjust speed for analyzing the entire surface of the test sample.
The Ø 20 mm silicon SDD detector provides the best accuracy in determining chemical elements in samples.
Working window of the programADK PRISMA-Mincludes:
- Measuring window with presentation of measurement results
- A set of tabs for working with measurement results
- Information on entering, editing and saving engine and aircraft passport data
- Tab for creating and editing a database of oil brands
- Laboratory personnel accounting tab
