Genetics-09U
Light-optical analysis equipment is used to visually determine the authenticity of documents in order to identify the presence or absence of luminescent marks in the objects under study. The device is used to check banknotes, documents, passports and any other types of printed products.
The Genetics 09 device is a cast block with built-in ultraviolet illuminators of different wavelengths. Additionally, the device can be equipped with a magnifying glass and a microscope.
Specifications:
- light wavelength – from 365 to 940 nm;
- UV wave strength – up to 4 mW/cm2;
- video quality – 640x480;
- Display dimensions – 4 inches.
The forensic unit for checking documents is used by the border and customs services of the Russian Federation. Order a forensic device from the SLS-GROUP company. Prices available on request. We will send your order to any city upon request.
Performance characteristics (TTX) of the Genetika-09U device:
| Parameter | Meaning |
| General Settings | |
| Size of the video camera observation field at a working distance (100 mm) from the video camera lens, mm | 50 x 35 |
| Size of the working area for transmission from lower sources of white radiation, mm | 150 x 70 |
| Intensity of ultraviolet (UV) radiation in the center of the working area of the device, mW/cm² | 3.5 |
| Illumination in the center of the working area of the device from overhead white light sources, kLx | 3.2 |
| Illumination in the center of the working area from lower sources of white light (backlight), kLx | 0.9 |
| UV emitter wavelength, nm | 365 |
| Built-in video camera resolution | 640 x 480 |
| Power supply of the device from the network via a stabilized network adapter | 220V/50Hz |
| Maximum power consumption from the network, W | 15 |
| Dimensions of the device working table, mm | 220 x 120 |
| Overall dimensions of the device, mm | 286 x 174 x 185 |
| Device weight, kg | 1.35 |
| Диапазон рабочей температуры, °C | +5 to +35 |
| Relative humidity at 25°C, % | 95 |
| Storage temperature range, °C | -40 to + 60 |
Delivery methods: delivery to the address, delivery by transport companies. We deliver throughout Russia. Delivery prices are calculated by sales managers. Delivery times are calculated depending on the equipment supplied and the conditions specified in the contract. Payment methods: We accept non-cash payments including VAT.
