Television inspection device KTS "SPRUT" MODEL 739
KTS "Sprut" ensures operational control of hard-to-reach and hidden places during inspection of cargo and containers, as well as inside and outside vehicles, including road, rail, air, sea and river transport under various weather conditions and lighting in order to detect and visually inspect foreign hidden objects (illegal investments). The system allows for inspections of premises through windows and technological openings in office and industrial buildings, structures and hangars in order to check the causes of alarms, extraneous noise or the presence of suspicious objects.
Additional photos:
Performance characteristics (TTX): KTS "SPRUT" MODEL 739
| №
p/p |
Parameter name | Parameter value |
|---|---|---|
| 1 | Length of extension elements (maximum/minimum length), cm:
|
170/60 450/120 102/62 |
| 2 | Screen diagonal size of visual display devices, inches: – compact HC – increased HC |
5.5 8.4 |
| 3 | Brightness of the LCD panel of visual display devices, cd/m2:
|
315 650 |
| 4 | Photosensitive element size (matrix resolution), dots | 2500 x 1900 (5 million dots) |
| 5 | Availability of a video camera with an ultra-wide-angle lens (field of view angle more than, degrees) | Included, (lens field of view angle – 135°) |
| 6 | Photo recording resolution, points | 1920×1432 (HD) |
| 7 | Video recording resolution, points | 640x480; 1280x720 (HD) |
| 8 | Weight of the equipped set of technical equipment, kg:
Weight of additional devices that facilitate the use of CTS, kg Weight of vehicle in transport position including spare parts, kg |
3.7 2.2 0.7 1.1 19 |
| 9 | Possibility of charging batteries from a 220V network, as well as from the on-board network of cars or trucks (12 or 24V) | Provided |
| 10 | Operating temperature range of the CTS, °C | From minus 35 up to +50 |
| 11 | Continuous battery life when using a standard set of batteries, hour. | 8.0 |
Scope of delivery:
| № p/p |
Name | Unit change | Qty |
|---|---|---|---|
| Set of technical means "Octopus" consisting of: | kit | 1 | |
| 4.1 4.1.1 4.1.2 4.1.3 |
Set of extension elements with eccentric clamps consisting of:
|
pcs. pcs. pcs. |
1 1 1 |
| 4.2
4.2.1
4.2.2 |
A set of rotary units with built-in video cameras and LED lighting elements:
|
pcs.
pcs. |
1
1 |
| 4.3
4.3.1 4.3.1.1 4.3.1.2 4.3.1.3 4.3.2 4.3.2.1 4.3.2.2 4.3.2.3 4.3.2.4 |
A set of portable visual display devices consisting of:
|
pcs. pcs. pcs. pcs. pcs. pcs. pcs. |
1 1 2 1 1 1 1 |
| 4.4 | Batteries | kit | 1 |
| 4.5 | Mains charger (charger) for batteries | pcs. | 1 |
| 4.6 4.6.1 4.6.2 |
Set of connecting cables (included in the charger): – power supply from the network 100-240 V; – power cord from the car cigarette lighter. |
pcs. pcs. |
1 1 |
| 4.7 | Exterior light | pcs. | 1 |
| 4.8 | Hardware joystick for controlling the endoscopic attachment | pcs. | 1 |
| 4.9 | Case for placing the KUV on the forearm | pcs. | 1 |
| 4.10 | Elbow and axillary support assembly | pcs. | 1 |
| 4.11 4.11.1 4.11.2 4.11.3 |
Auxiliary fastening elements for UUV:
|
pcs. pcs. pcs. |
1 1 1 |
| 4.12 4.12.1 4.12.2 4.12.3 4.12.4 |
ZIP-O consisting of:
|
kit kit pcs. pcs. |
1 1 1 1 |
| 4.13 4.13.1 4.13.2 4.13.3 4.13.4 4.13.5 |
Operational documentation including:
|
copy copy copy copy copy |
1 1 1 1 1 |
| 4.14 | Certificate of conformity (appendix to the OM) | copy | 1 |
| 4.15 | Expert opinion (appendix to the OM) | copy | 1 |
| 4.16 | Stowing case | pcs. | 1 |
Delivery methods: delivery to the address, delivery by transport companies. We deliver throughout Russia. Delivery prices are calculated by sales managers. Delivery times are calculated depending on the equipment supplied and the conditions specified in the contract. Payment methods: We accept non-cash payments including VAT.
