Shmel 240TV
Portable X-ray television complex "Shmel 240TV"
The X-ray television complex “Shmel 240TV” is a domestic development and is used for non-contact inspection of objects using x-rays. Adopted by the Federal Customs Service of the Russian Federation. The complex is constantly being modernized in order to ensure maximum convenience for personnel when constantly working with the complex. Indispensable when carrying out inspections at mobile checkpoints, where it is not possible to install and operate stationary inspection systems and complexes
Performance characteristics (TTX): Shmel 240TV
| Penetration on steel, mm | 40 |
| Autonomous mode, h. | 3 |
| Image acquisition time, sec | 5 |
| Operating temperature range, C | From 0 to +40 (in difficult climatic conditions, short-term operation at temperatures -10....+50 is allowed) |
| Database capacity, snapshots | 40,000 |
| Control unit weight, kg | 11.7 |
| Overall dimensions of the control unit, mm | 478 x 176 x 355 |
| Weight of X-ray machine “Shmel 240A”, kg | 9.8 |
| Overall dimensions of “Shmel 240A”, mm | 421x112x221 |
| X-ray optical converter control zone | 320x240 |
| Weight of X-ray optical converter, kg | 6.0 |
| Overall dimensions of the X-ray optical converter | 353x180x385 |
| Feature Set | – 0.5 – 5-fold image scaling;
– smooth adjustment of brightness and contrast; – scale grid; – negative-positive; – pseudo-coloring; "relief"; – nonlinear filtering; – stereo image; – region of interest (ROI) |
Delivery methods: delivery to the address, delivery by transport companies. We deliver throughout Russia. Delivery prices are calculated by sales managers. Delivery times are calculated depending on the equipment supplied and the conditions specified in the contract. Payment methods: We accept non-cash payments including VAT.
