X-ray television installation (introscope) Astrophysics “XIS-100X”
X-ray television installation Astrophysics “XIS-100X”
XIS-100X is a universal X-ray television installation with tunnel dimensions of 101.6 cm x 101.3 cm. XIS-100X is designed for inspection of large luggage, large parcels and small cargo.
The XIS-100X is a medium-sized unit that has an optimal tunnel for inspecting large items with minimal dimensions. The installation provides high throughput and efficiency. The XIS-100X is a cost-effective solution for security screening at airports, customs and cargo terminals.
All Astrophysics installations are equipped with a continuous condition diagnostics system. This function allows you to monitor and identify faults at an early stage of their manifestation, which increases service life, reduces the cost of operation and possible repairs.
A large set of functions in the basic configuration. Russified keyboard and software. Another distinctive feature of Astrophysics installations is the formation of images of inspected objects in a 6-color format (depending on the atomic number of the substance), which greatly facilitates the operator’s work in identifying hazardous materials. A large number of options are included in the standard configuration, including Russian-language software and keyboard, 6-color image, real-time diagnostics.
Performance characteristics (TTX):
| Dimensions | |
| Tunnel size | 1016 x 1013 mm |
| Overall dimensions, no more | 2775 x 1372 x 1919 mm |
| Packaging dimensions | 2972 x 1500 x 2240 mm |
| Weight, no more | 980 kg |
| Package weight | 1300 kg |
| Conveyor | |
| Maximum distributed load on
conveyor | 200 kg |
| Conveyor height | 720 mm |
| Conveyor belt speed | 0.23 m/s |
| X-ray source | |
| Anode voltage | 180 kV (operating 165 kV) |
| Source current | 1.2 mA |
| Radiation direction | diagonally up |
| Cooling system | oil bath with air (convection)
cooling |
| Film safety | up to ISO 1600 (33 DIN) |
| X-ray receiver | |
| Type | L-shaped array |
| Dual energy technology | availability |
| Gray levels | 4096 |
| Detective ability for copper
wire | 0.07 mm (40 AWG) – 0.08 mm (38 AWG) |
| Penetration ability on steel | 39 – 37 mm |
| Spatial resolution, line pairs per mm | 1.0 mm |
| Visible contrast levels, not less | 24 |
| Operator workstation parameters | |
| Monitor | Two 19” LCD monitors
1280 x 1024, 24-bit |
| Image archive | 100.000 images |
| Power supply | |
| Voltage | 220V (±10%), 50 Hz, 10 A max |
| Climatic conditions | |
| Workers: | |
| – ambient temperature | 0° – +40 °С |
| – relative humidity | up to 95%, no condensation |
| During storage: | |
| – ambient temperature | -20° – +60 °С |
| – relative humidity | up to 95%, no condensation |
Delivery methods: delivery to the address, delivery by transport companies. We deliver throughout Russia. Delivery prices are calculated by sales managers. Delivery times are calculated depending on the equipment supplied and the conditions specified in the contract. Payment methods: We accept non-cash payments including VAT.
