X-ray television installation (introscope) Astrophysics “XIS 100XDV”
X-ray television installation Astrophysics «XIS100XDV»
The XIS-100XDV two-projection X-ray television installation with tunnel dimensions of 101.6 cm x 101.6 cm is designed for use in places with increased security requirements - airports, military and government facilities.
Equipped with two generators, the XIS-100XDV displays the inspected object from two angles and allows you to independently control each image. This increases the likelihood of identifying a potential threat without reducing the speed of inspection.
The combination of dual-view technology and Astrophysics software in the XIS-100XDV allows it to be used for inspecting large objects in areas with high security requirements.
All Astrophysics installations are equipped with a continuous condition diagnostics system. This function allows you to monitor and identify faults at an early stage of their manifestation, which increases service life, reduces the cost of operation and possible repairs.
Another distinctive feature of Astrophysics installations is the formation of images of inspected objects in a 6-color format (depending on the atomic number of the substance), which greatly facilitates the operator’s work in identifying hazardous materials. A large number of options are included in the standard configuration, including Russian-language software and keyboard, 6-color image, real-time diagnostics.
Performance characteristics (TTX):
| Dimensions | |
| Tunnel size | 1016 x 1016 mm |
| Overall dimensions, no more | 3134 x 1734 x 1959 mm |
| Packaging dimensions | 3302 x 1943 x 2250 mm |
| Weight, no more | 1435 kg |
| Package weight | 1600 kg |
| Conveyor | |
| Maximum distributed load on
conveyor | 200 kg |
| Conveyor height | 760 mm |
| Conveyor belt speed | 0.23 m/s |
| X-ray source | |
| Anode voltage | Two 180 kV (working 165 kV) |
| Source current | 1.2 mA each |
| Radiation direction | diagonally up, horizontally to the side |
| Cooling system | oil bath with air (convection)
cooling |
| Film safety | up to ISO 1600 (33 DIN) |
| X-ray receiver | |
| Type | L-shaped array |
| Dual energy technology | availability |
| Gray levels | 4096 |
| Detective ability for copper
wire | 0.07 mm (40 AWG) – 0.08 mm (38 AWG) |
| Penetration ability on steel | 37 – 35 mm |
| Spatial resolution, line pairs per mm | 1.0 mm |
| Visible contrast levels, not less | 24 |
| Operator workstation parameters | |
| Monitor | Two 24” LCD monitors
1600 x 1200, 24-bit |
| Image archive | 150,000 images |
| Power supply | |
| Voltage | 220V (±10%), 50 Hz, 10 A max |
| Climatic conditions | |
| Workers: | |
| – ambient temperature | 0° – +40 °С |
| – relative humidity | up to 95%, no condensation |
| During storage: | |
| – ambient temperature | -20° – +60 °С |
| – relative humidity | up to 95%, no condensation |
