X-ray television installation (introscope) Astrophysics “XIS 100XDX”
X-ray television installation Astrophysics “XIS 100XDX”
The XIS-100XDX is a 100.0 cm x 100.0 cm dual projection X-ray camera. The XIS-100XDX combines dual projection technology with a low conveyor position (30 cm from the floor) for inspection of heavy objects.
The XIS-100XDX uses two generators that produce two images from different angles. Combined with 6-color display, this allows operators to carry out inspections quickly and efficiently. The XIS-100XDX low conveyor makes it easy to load and unload heavy inspection items.
All Astrophysics installations are equipped with a continuous condition diagnostics system. This function allows you to monitor and identify faults at an early stage of their manifestation, which increases service life, reduces the cost of operation and possible repairs.
Another distinctive feature of Astrophysics installations is the formation of images of inspected objects in a 6-color format (depending on the atomic number of the substance), which greatly facilitates the operator’s work in identifying hazardous materials. A large number of options are included in the standard configuration, including Russian-language software and keyboard, 6-color image, real-time diagnostics.
Performance characteristics (TTX):
| Dimensions | |
| Tunnel size | 1000 x 1000 mm |
| Overall dimensions, no more | 3120 x 1832 x 1886 mm |
| Packaging dimensions | 3302 x 1943 x 2250 mm |
| Weight, no more | 1605 kg |
| Package weight | 1845 kg |
| Conveyor | |
| Maximum distributed load on
conveyor | 200 kg |
| Conveyor height | 300 mm |
| Conveyor belt speed | 0.23 m/s |
| X-ray source | |
| Anode voltage | Two 180 kV (working 165 kV) |
| Source current | 1.0 mA each |
| Radiation direction | diagonally up, horizontally to the side |
| Cooling system | oil bath with air (convection)
cooling |
| Film safety | up to ISO 1600 (33 DIN) |
| X-ray receiver | |
| Type | L-shaped array |
| Dual energy technology | availability |
| Gray levels | 4096 |
| Detective ability for copper
wire | 0.07 mm (40 AWG) – 0.08 mm (38 AWG) |
| Penetration ability on steel | 37 – 35 mm |
| Spatial resolution, line pairs per mm | 1.0 mm |
| Visible contrast levels, not less | 24 |
| Operator workstation parameters | |
| Monitor | Two 24” LCD monitors
1600 x 1200, 24-bit |
| Image archive | 150,000 images |
| Power supply | |
| Voltage | 220V (±10%), 50 Hz, 10 A max |
| Climatic conditions | |
| Workers: | |
| – ambient temperature | 0° – +40 °С |
| – relative humidity | up to 95%, no condensation |
| During storage: | |
| – ambient temperature | -20° – +60 °С |
| – relative humidity | up to 95%, no condensation |
