X-ray television installation (introscope) Astrophysics “XIS 5335SD”
X-ray television installation Astrophysics «XIS5335SD»
The XIS-5335SD is a compact X-ray camera with a tunnel size of 53 cm x 34.4 cm. The XIS-5335SD has increased penetration capability and is ideal for inspecting small objects, detecting liquid explosives, improvised explosive devices, contraband, drugs and weapons.
The unit is equipped with a 160 kV X-ray generator, which provides improved image quality and unrivaled penetration power. The top location of the generator provides downward-directed X-ray radiation and a low conveyor height of 29.3 cm.
Thanks to its small size, the XIS-5335SD is easy to move and allows you to organize an inspection point in a limited area.
All Astrophysics installations are equipped with a continuous condition diagnostics system. This function allows you to monitor and identify faults at an early stage of their manifestation, which increases service life, reduces the cost of operation and possible repairs.
Another distinctive feature of Astrophysics installations is the formation of images of inspected objects in a 6-color format (depending on the atomic number of the substance), which greatly facilitates the operator’s work in identifying hazardous materials. A large number of options are included in the standard configuration, including Russian-language software and keyboard, 6-color image, real-time diagnostics.
Performance characteristics (TTX):
| Dimensions | |
| Tunnel size | 530 x 344 mm |
| Overall dimensions, no more | 1377 x 765 x 1071 mm |
| Packaging dimensions | 1588 x 965 x 1651 mm |
| Weight, no more | 355 kg |
| Package weight | 485 kg |
| Conveyor | |
| Maximum distributed load on
conveyor | 165 kg |
| Conveyor height | 293 mm |
| Conveyor belt speed | 0.23 m/s |
| X-ray source | |
| Anode voltage | 160 kV (operating 150 kV) |
| Source current | 0.7 mA |
| Radiation direction | diagonally down |
| Cooling system | oil bath with air (convection)
cooling |
| Film safety | up to ISO 1600 (33 DIN) |
| X-ray receiver | |
| Type | L-shaped array |
| Dual energy technology | availability |
| Gray levels | 4096 |
| Detective ability for copper
wire | 0.08 mm (40 AWG) – 0.10 mm (38 AWG) |
| Penetration ability on steel | 39 – 37 mm |
| Spatial resolution, line pairs per
mm | 1.0 mm |
| Visible contrast levels, not less | 24 |
| Operator workstation parameters | |
| Monitor | LCD monitor 19”
1280 x 1024, 24-bit |
| Image archive | 150,000 images |
| Power supply | |
| Voltage | 220V (±10%), 50 Hz, 10 A max |
| Climatic conditions | |
| Workers: | |
| – ambient temperature | 0° – +40 °С |
| – relative humidity | up to 95%, no condensation |
| During storage: | |
| – ambient temperature | -20° – +60 °С |
| – relative humidity | up to 95%, no condensation |
