X-ray television installation (introscope) Astrophysics “XIS 7555R”
The XIS-7555R is a 75.6 cm x 55.2 cm X-ray television unit designed for outdoor use. The entire frame is completely made of stainless steel, painted with powder paint containing a special anti-corrosion compound. XIS-7555R is a mobile unit and is equipped with vibration damping mounts. Ideal for use in marine environments (ships, ports), deserts and other harsh conditions.
The XIS-7555R uses a 180kV generator to provide improved penetration and recognition of suspicious objects. All Astrophysics installations are equipped with a continuous condition diagnostics system. This feature allows you to monitor and identify faults at an early stage of their occurrence, which increases service life, reduces operating costs and
possible repairs.
Another distinctive feature of Astrophysics installations is the formation of images of inspected objects in a 6-color format (depending on the atomic number of the substance), which greatly facilitates the operator’s work in identifying hazardous materials. A large number of options are included in the standard configuration, including Russian-language software and keyboard, 6-color image, real-time diagnostics.
Performance characteristics (TTX):
| Dimensions | |
| Tunnel size | 765 x 552 mm |
| Overall dimensions, no more | 1897 x 1063 x 1643 mm |
| Packaging dimensions | 2083 x 1143 x 2032 mm |
| Weight, no more | 810 kg |
| Package weight | 995 kg |
| Conveyor | |
| Maximum distributed load on
conveyor | 165 kg |
| Conveyor height | 825 mm |
| Conveyor belt speed | 0.23 m/s |
| X-ray source | |
| Anode voltage | 180 kV (operating 165 kV) |
| Source current | 1.2 mA |
| Radiation direction | diagonally up |
| Cooling system | oil bath with air (convection)
cooling |
| Film safety | up to ISO 1600 (33 DIN) |
| X-ray receiver | |
| Type | L-shaped array |
| Dual energy technology | availability |
| Gray levels | 4096 |
| Detective ability for copper
wire | 0.08 mm (40 AWG) – 0.10 mm (38 AWG) |
| Penetration ability on steel | 39 – 37 mm |
| Spatial resolution, line pairs per mm | 1.0 mm |
| Visible contrast levels, not less | 24 |
| Operator workstation parameters | |
| Monitor | LCD monitor 19”
1280 x 1024, 24-bit |
| Image archive | 150,000 images |
| Power supply | |
| Voltage | 220V (±10%), 50 Hz, 15 A max |
| Climatic conditions | |
| Workers: | |
| – ambient temperature | -17° – +50 °С |
| During storage: | |
| – ambient temperature | -37° – +60 °С |
