GARRETT Magnascanner CS 5000
Metal detector "Garrett 5000"
The Garrett Magnascanner is designed for continuous screening of people and objects and detects the presence of metal.
Key Features:
- weight – 45 kg;
- passage width – 80 cm;
- throughput – 50 people per minute;
- 20 built-in programs;
- 200 sensitivity frequencies;
- light and sound indication;
- self-diagnosis;
- touch control.
The device is an arch, which consists of wide panels connected by a cross beam. Inside the vertical panels there is a control and monitoring panel, as well as signal elements. Impact-resistant aluminum panels are protected from accidental mechanical damage, as well as moisture.
Operating principle
The Garrett CS 5000 arch-type device is equipped with a built-in microprocessor that is responsible for automated control. The CS 5000 metal detector detects objects made of non-ferrous and ferrous metal, even if they are carefully camouflaged. When you bring metal objects through the Garrett CS 5000 arched metal detector, a sound and color indication is triggered.
Thanks to its built-in processor, the Garrett CS 5000 metal detector provides accurate inspection and does not affect the flow of people. Thanks to precise settings, the operator can change the sensitivity of the device. The operator can control the Garrett 5000 metal detector remotely, as well as configure special functions:
- metal search;
- protection from interference transmitted by monitors and other equipment;
- eliminating the camouflage of metal objects with different magnetic poles;
- constant transmission of detector operation to the monitor;
- self-diagnosis;
- setting up several devices within the same range.
The Garrett Magnascanner metal detector detects the smallest metal objects, such as keys, key fobs, and coins. Settings can be adjusted by changing the mode and sensitivity.
Application
The Garrett 5000 metal detector is installed in crowded places. They are used as a security measure in theaters, schools, government agencies, shopping centers, complexes, and stadiums.
The operator selects the program depending on the operating conditions. The sensitivity mode is also customizable depending on the conditions. The Garrett Magnascanner CS5000's built-in LCD monitor displays operating parameters, making operation and settings easy.
The digital filtering parameter eliminates false positives due to extraneous noise from office equipment or other devices. You can install several Garrett Magnascanner CS 5000 metal detectors in one room and control them simultaneously. Before installation and connection, please use the instructions for use.
Pricing for the Garrett Magnascanner CS 5000 is available upon request. We will send your order to any city upon request.
Performance characteristics (TTX): GARRETT Magnascanner CS 5000
| External dimensions | 0.9x 2.2x0.58 m |
| Tunnel internal dimensions | 0.76x2x0.58 m |
| Power supply | 100-240 V, 50/60 Hz, 5 W |
| Operating frequency | < 7 kHz |
| Operating temperature range | -20…+70 °C |
| Humidity | up to 95% without direct condensation |
| Weight | 45 kg |
