X-ray television installation Berg 100100
The Berg 100100 X-ray television installation is designed for inspection of large bags, packages, medium and large boxes and other small and medium-sized luggage.
A large number of options for the basic configuration of the RTU, as well as additional options, makes the Berg 100100 introscope a multifunctional X-ray television system that is beneficial for our customers.
Areas of application:
- Railway stations.
- Airports and airfields.
- Border checkpoints and customs.
- Judicial buildings.
- Government buildings.
- Post offices.
- Offices and shopping centers.
- Correctional facilities.
Basic equipment of the Berg 100100 introscope:
– B-Sight – detection of explosives and narcotic substances;
– B-Zoom – optimal scaling of the shadow image;
– B-TIP – operator vigilance training;
– B-Density– identification of areas with high density of material (to identify bladed weapons and firearms);
– B-View – video recording of a person when feeding luggage into the introscope for the purpose of automatically identifying the owner of the luggage;
– B-Export – transfer of shadow images to a USB drive in image format – JPG;
-B-Store – storage of shadow images in a maximum quantity of 200,000 pieces.
Optional:
– Information system for persons undergoing inspection – “Assistant”;
– Operator training system;
– Dosimetric monitoring of the X-ray unit operator’s workplace;
– Radiation control of luggage;
– Remote console for connecting a remote control, monitor and USB storage devices;
– Possibility of integrating equipment into a single inspection complex;
– Scanning in two directions (reverse).
Tactical and technical characteristics (TTX) of the Berg 100100 introscope:
| Name: | Meaning: |
| Tunnel size | 1010x1010 mm |
| Weight, net | 1200 kg |
| Installation length | 3396 mm |
| Installation width | 1300 mm |
| Installation height | 2145 mm |
| Maximum permissible load on the conveyor | 200 kg |
| Conveyor height | 300 mm |
| Conveyor speed | 0.2 m/s |
| Duty cycle | Around the clock |
| Steel penetration | 40 mm |
| Wire resolution | 0.127 mm |
| Operating temperature | 0 ÷ +45 °C |
| Storage temperature | -40 ÷ +60 °C |
| Humidity | 20% – 95%, no condensation allowed |
| Display Mode | Black and white/color |
