X-ray television installation (introscope) Astrophysics “XIS 1210D”
X-ray television installation Astrophysics “XIS 1210D”
XIS-1210D is an X-ray television inspection installation with tunnel dimensions of 120.0 cm x 100.0 cm. The lower location of the conveyor (30 cm from the floor) facilitates the inspection of heavy cargo.
The 180 kV generator and modern image processing technologies used in the XIS-1210D allow for fast and high-quality inspection of cargo.
With a large tunnel size, the XIS-1210D occupies a small area, which allows you to organize the inspection of large luggage in a limited space.
All Astrophysics installations are equipped with a continuous condition diagnostics system. This function allows you to monitor and identify faults at an early stage of their manifestation, which increases service life, reduces the cost of operation and possible repairs.
Another distinctive feature of Astrophysics installations is the formation of images of inspected objects in a 6-color format (depending on the atomic number of the substance), which greatly facilitates the operator’s work in identifying hazardous materials. A large number of options are included in the standard configuration, including Russian-language software and keyboard, 6-color image, real-time diagnostics.
A large number of options are included in the standard configuration, including Russian-language software and keyboard, 6-color image, real-time diagnostics.
Performance characteristics (TTX):
| Dimensions | |
| Tunnel size | 1200 x 1000 mm |
| Overall dimensions, no more | 2863 x 1459 x 1887 mm |
| Packaging dimensions | 2032 x 1626 x 2235 mm |
| Weight, no more | 885 kg |
| Package weight | 1105 kg |
| Conveyor | |
| Maximum distributed load on
conveyor | 200 kg |
| Conveyor height | 300 mm |
| Conveyor belt speed | 0.23 m/s |
| X-ray source | |
| Anode voltage | 180 kV (operating 165 kV) |
| Source current | 1.2 mA |
| Radiation direction | vertically down |
| Cooling system | oil bath with air (convection)
cooling |
| Film safety | up to ISO 1600 (33 DIN) |
| X-ray receiver | |
| Type | L-shaped array |
| Dual energy technology | availability |
| Gray levels | 4096 |
| Detective ability for copper
wire | 0.07 mm (40 AWG) – 0.08 mm (38 AWG) |
| Penetration ability on steel | 37 – 35 mm |
| Spatial resolution, line pairs per mm | 1.6 mm |
| Visible contrast levels, not less | 24 |
| Operator workstation parameters | |
| Monitor | Two 24” LCD monitors
1600 x 1200, 24-bit |
| Image archive | 100.000 images |
| Power supply | |
| Voltage | 220V (±10%), 50 Hz, 10 A max |
| Climatic conditions | |
| Workers: | |
| – ambient temperature | 0° – +40 °С |
| – relative humidity | up to 95%, no condensation |
| During storage: | |
| – ambient temperature | -20° – +60 °С |
| – relative humidity | up to 95%, no condensation |
