X-ray television installation (introscope) Astrophysics “XIS 1818DV (200)”
X-ray television installation Astrophysics “XIS 1818DV (200)”
XIS-1818DV (200kV) is a high-performance X-ray television inspection unit with increased tunnel dimensions of 180.3 cm x 180.5 cm. XIS-1818DV (200kV) is designed for inspection of large and palletized cargo at airports and seaports. It's also perfect
for any location where large inspection systems are required.
Due to the high strength and rigidity of the structure, the XIS-1818DV (200kV) roller conveyor can withstand loads of up to 3000 kg. XIS-1818DV (200kV) provides high performance while maintaining high throughput.
The combination of the special capabilities of Astrophysics software and advanced technology allows the XIS-1818DV (200kV) to be used to solve a wide range of inspection tasks.
All Astrophysics installations are equipped with a continuous condition diagnostics system. This function allows you to monitor and identify faults at an early stage of their manifestation, which increases service life, reduces the cost of operation and possible repairs.
Another distinctive feature of Astrophysics installations is the formation of images of inspected objects in a 6-color format (depending on the atomic number of the substance), which greatly facilitates the operator’s work in identifying hazardous materials. A large number of options are included in the standard configuration, including Russian-language software and keyboard, 6-color image, real-time diagnostics.
Performance characteristics (TTX):
| Dimensions | |
| Tunnel size | 1803 x 1805 mm |
| Overall dimensions, no more | 8531 x 2896 x 3166 mm |
| Packaging dimensions | 1x 3251 x 1435 x 2540 mm
2x 2331 x 1435 x 2540 mm 3x 2032 x 2235 x 813 mm 4x 2331 x 1435 x 1092 mm |
| Weight, no more | 5800 kg |
| Package weight | 7300 kg |
| Conveyor | |
| Maximum distributed load on
conveyor | 3000 kg |
| Conveyor height | 383 mm |
| Conveyor belt speed | 0.10 m/s |
| X-ray source | |
| Anode voltage | two 200 kV |
| Source current | 1.0 mA each |
| Radiation direction | horizontally sideways, vertically downwards |
| Cooling system | oil bath with air (convection)
cooling |
| Film safety | up to ISO 1600 (33 DIN) |
| X-ray receiver | |
| Type | L-shaped array |
| Dual energy technology | availability |
| Gray levels | 4096 |
| Detective ability for copper
wire | 0.07 mm (40 AWG) – 0.08 mm (38 AWG) |
| Penetration ability on steel | 52 – 50 mm |
| Spatial resolution, line pairs per mm | 1.3 mm |
| Visible contrast levels, not less | 24 |
| Operator workstation parameters | |
| Monitor | Two 24” LCD monitors
1600 x 1200, 24-bit |
| Image archive | 150,000 images |
| Power supply | |
| Voltage | 220V (±10%), 50 Hz, 15 A max |
| Climatic conditions | |
| Workers: | |
| – ambient temperature | 0° – +40 °С |
| – relative humidity | up to 95%, no condensation |
| During storage: | |
| – ambient temperature | -20° – +60 °С |
| – relative humidity | up to 95%, no condensation |
Delivery methods: delivery to the address, delivery by transport companies. We deliver throughout Russia. Delivery prices are calculated by sales managers. Delivery times are calculated depending on the equipment supplied and the conditions specified in the contract. Payment methods: We accept non-cash payments including VAT.
