Infrared banknote detector "DORS 1100"
IR detectors are used to check securities, banknotes, banknotes, documents, and excise taxes for authenticity. If you need an accurate device that makes it possible to quickly and accurately identify objects using infrared marks, you can use the DORS 1100 detector.
Peculiarities
The device is compact and takes up little space. Wide range of applications: the device is indispensable in border and customs services, at checkpoints, as well as in various enterprises where employees are forced to accept money.
The DORS 1100 banknote detector is equipped with a video camera in which an infrared filter is mounted. Illumination makes it possible to identify counterfeit bills, as well as accurately determine their difference from the originals. The device is equipped with a color LCD display and touch controls.
Specifications:
- Electricity consumption – 20W;
- dimensions – 11x15x30 cm;
- weight – 650 g;
- IR wavelength – 850-940 nm;
- Display size: 12.7 cm (5 inches).
Operating principle
To check, you need to place the bill on the viewing area. If the bill is positioned correctly, an image will appear on the monitor of the DORS 1100 infrared detector. The operator can move the bill to check individual zones. Brightness and contrast can be changed independently. For convenience, a graphic editor is displayed on the screen to make it more convenient to set indicators. In addition, the operator can also set an automatic shutdown timer, which will work 10-180 minutes after switching on.
If you need to view the resulting image in detail, it can be transferred to a PC or external monitor. The DORS infrared detector receives a video signal from external sources through the video input, which is located on the rear panel of the device.
The device operates from the mains and from a car battery, so if necessary, it can be used in “field” conditions.
DORS 1100 can be purchased from SLS-GROUP LLC. Leave a request for DORS 1100, prices and we will send a commercial offer by email. Delivery is carried out to all cities of the Russian Federation.
Performance characteristics (TTX) of the DORS 1100 currency detector:
| Power consumption 20 W | |
| Device dimensions (LxWxH) | 110x150x295 mm |
| Dimensions in packaging (LxWxH) | 195x185x335 mm |
| Weight | 0.65 kg |
| Package weight | 1.2 kg |
| Wavelength of IR emitters | 940/850 nm |
| Number of lamps | 1 piece |
| LCD display | 5 inches (12.7 cm) |
| Supply voltage | 110-220/50 V/Hz |
Delivery methods: delivery to the address, delivery by transport companies. We deliver throughout Russia. Delivery prices are calculated by sales managers. Delivery times are calculated depending on the equipment supplied and the conditions specified in the contract. Payment methods: We accept non-cash payments including VAT.
