Two-projection X-ray television installation for inspection of luggage and goods SDT 100100 D
Modern, ergonomic two-projection introscope with a lower conveyor location and a spacious tunnel. Provides excellent image detail and is ideal for screening large luggage and small cargo.
Key Features:
▪ Possibility of choosing a 4 or 7 color palette.
▪ Accurate separation of substances by atomic mass:
only organic / mixed / only synthetic.
▪ Automatic detection of suspicious substances: hazardous liquids, explosives, drugs, weapons.
▪ Possibility of remote access via Ethernet network.
Main technical characteristics of the X-ray television installation SDT 100100 D
| Specifications | ||
| Installation size, mm (L x W x H) | 3690* x 1587 ±5 x 1801** | |
| Tunnel size, mm (W x H) | 1010 x 1005 ±10 | |
| Maximum power consumption, kW | no more than 1.4 | |
| System weight, kg | no more than 1120 | |
| Penetration on steel, mm | 32-34 | |
| Number of projections | Two | |
| Conveyor belt speed, m/s | ≥0.2 | |
| Maximum distributed load on the conveyor, kg | 250 | |
| 3D function | No | |
| Maximum contrast on copper wire, mm | 0.1-0.13 | |
| Standard size | Big | |
| Conveyor height above floor level, mm | 301 | |
| Operating temperature | 0°С – +50°С | |
| Power supply | 220V±10% 55±5 Hz, with grounding | |
* – The length is indicated subject to the zero position of the conveyor belt tensioner. The tensioner stroke is no more than 30 mm.
** – The height is indicated from the transport wheels of the installation to the upper plane of the RTU. The travel of stationary legs is no more than 50 mm.
Equipment SDT 100100 D:
- X-ray television installation – 1 piece
- Monitor configuration at the Customer's choice:
1) Curved LCD monitor 34” – 1 pc.
2) Standard LCD monitor 24″ – 2 pcs. - Operator control panel – 1 piece
- Operational documentation, passport (form)
Additional options:
- Input/output roller table 0.5 m
- Input/output roller table 1 m
- Built-in surveillance video cameras for recording luggage, objects and their owners
- Intelligent subsystem for automatic stop/start of the conveyor belt (extends the service life of the conveyor and saves energy consumption)
- Artificial intelligence-based subsystem for monitoring operator attention (vigilance / fatigue / operator absence from the workplace)
- Keyboard/mouse kit
- Voltage stabilizer
- Uninterruptible power supply
- Operator's desktop with 2 monitors
