X-ray television installation for inspection of luggage and goods SDT 6040 D
Modern, ergonomic, two-projection X-ray television installation. Provides the highest image detail, suitable for quickly and efficiently checking carry-on luggage, luggage and other medium-sized items.
Features SDT 6040 D
- The dual-generator installation allows scanning objects both vertically and horizontally simultaneously, thereby providing the operator with unsurpassed inspection quality and the complete absence of dead zones
- Suitable for high traffic areas
- User-friendly software interface and ergonomic operator control panel
- Innovative scanning technology with a palette of 7 colors
- More than 30 image processing functions
- Accurate separation of materials into organic, mixed, inorganic
- Built-in function for identifying suspicious objects based on artificial intelligence
- Windows-based software ensures high performance and stable operation
Two projections on one monitor. Ability to switch scan display modes on the monitor in horizontal or vertical scan
Function for highlighting suspicious objects
An assistant that allows the release of dangerous, flammable substances, explosives or drugs
Ability to select images in a 4-color or 7-color palette
Main technical characteristics of the X-ray television installation SDT 6040 D
| Specifications | ||
| Installation size, mm (L x W x H) | 2003* x 1193 ±5 x 1300** | |
| Tunnel size, mm (W x H) | 625 x 421 ±10 | |
| X-ray direction | Bottom-up, side | |
| Penetration on steel, mm | 34-36 | |
| Conveyor belt speed, m/s | ≥0.2 | |
| Maximum distributed load on the conveyor, kg | 165 | |
| Color palette | Choice of: 4 or 7 colors | |
| Separation of objects by atomic mass | Availability | |
| Maximum power consumption, kW | no more than 1.2 | |
| System weight, kg | no more than 600 | |
| Number of projections | Two | |
| 3D function | No | |
| Maximum contrast on copper wire, mm | 0.08-0.1 | |
| Standard size | Compact | |
| Conveyor height above floor level, mm | 709 | |
| Power supply | 220V±10% 55±5 Hz, with grounding | |
| Operating temperature | 0°С – +50°С | |
* – The length is indicated subject to the zero position of the conveyor belt tensioner. The tensioner stroke is no more than 30mm.
** – The height is indicated from the transport wheels of the installation to the upper plane of the RTU. The travel of stationary legs is no more than 50mm.
Equipment SDT 6040 D:
- X-ray television installation – 1 pc.
- Monitor configuration at customer's choice:
1) Curved LCD monitor 34” – 1 pc.
2) Standard LCD monitor 24″ – 2 pcs. - Operator control panel – 1 pc.
- Operational documentation, passport (form)
Additional options available to order:
- Input/output roller table 0.5 m
- Input/output roller table 1 m
- Surveillance video cameras built into the RTU
- Intelligent subsystem for automatic stop/start of the conveyor belt (extends the service life of the installation and saves energy)
- Artificial intelligence-based subsystem for monitoring operator attention (vigilance / fatigue / operator absence from the workplace)
- Keyboard/mouse kit
- Voltage stabilizer
- UPS
- Operator's desktop with 2 monitors
