X-ray television installation (introscope) Rapiscan 618XR
X-ray television installation "Rapiscan618XR»
The Rapiscan 618XR X-ray television installation is one of the most popular systems in the world for the inspection and control of hand luggage and baggage at airports, customs checkpoints, as well as at checkpoints of specially protected facilities. The combination of basic tactical and technical characteristics makes the installation a leader in sales and operation in more than 50 countries around the world for inspection. The system's modular design and hinged, easily accessible panels provide excellent reliability and ease of maintenance. The Rapiscan 618XR X-ray unit uses exclusive diode array developments and recognition and imaging algorithms that provide maximum levels of hazardous object detection and material separation that are available with standard X-ray systems.
The system can also be equipped with the TARGET function, which allows you to automatically recognize potentially dangerous objects if their characteristics match those corresponding to explosives or drugs. The Rapiscan 618XR introscope is the new standard in security worldwide. The feature-rich OS6000 operating system adds a wealth of options to an already excellent product.
Performance characteristics (TTX): Rapiscan 618XR
| Tunnel size, mm | 550 x 360 |
| Overall dimensions of the installation | 1662 x 1368 x 735 |
| Load capacity, kg | 165 |
| Operating temperature range, C | From 0 to +40 (in difficult climatic conditions it is possible to install additional cooling systems to avoid overheating) |
| Conveyor speed, m/s | 0.22 |
| Installation weight, kg | NET 403 |
| Ready to work time, sec | 10 |
| Work cycle | around the clock |
| Penetration on steel, mm | 27 (guaranteed) / 30 (standard) |
| Resolution, mm | 38 AWG (standard) / 40 (guaranteed) |
| X-ray tube, voltage | 140kV (160kV option available with 35mm steel penetration) |
