X-ray television installation (introscope) Astrophysics “XIS 1080”
X-ray television installation Astrophysics “XIS 1080”
XIS-1080 is a medium-sized X-ray television inspection unit with tunnel dimensions of 101.6 cm x 81.4 cm. XIS-1080 is designed for inspection of standard and oversized luggage, as well as large objects.
The XIS-1080 is ideal for inspecting large objects with small external dimensions of the installation itself. The reinforced belt conveyor can withstand loads of up to 200 kg, which allows for inspection of heavy loads.
All Astrophysics installations are equipped with a continuous condition diagnostics system. This function allows you to monitor and identify faults at an early stage of their manifestation, which increases service life, reduces the cost of operation and possible repairs.
Another distinctive feature of Astrophysics installations is the formation of images of inspected objects in a 6-color format (depending on the atomic number of the substance), which greatly facilitates the operator’s work in identifying hazardous materials. A large number of options are included in the standard configuration, including Russian-language software and keyboard, 6-color image, real-time diagnostics.
Performance characteristics (TTX):
| Dimensions | |
| Tunnel size | 1016 x 814 mm |
| Overall dimensions, no more | 2574 x 1372 x 1706 mm |
| Packaging dimensions | 2972 x 1473 x 2240 mm |
| Weight, no more | 900 kg |
| Package weight | 1240 kg |
| Conveyor | |
| Maximum distributed load on
conveyor | 200 kg |
| Conveyor height | 706 mm |
| Conveyor belt speed | 0.23 m/s |
| X-ray source | |
| Anode voltage | 180 kV (operating 165 kV) |
| Source current | 1.2 mA |
| Radiation direction | diagonally up |
| Cooling system | oil bath with air (convection)
cooling |
| Film safety | up to ISO 1600 (33 DIN) |
| X-ray receiver | |
| Type | L-shaped array |
| Dual energy technology | availability |
| Gray levels | 4096 |
| Detective ability for copper
wire | 0.07 mm (40 AWG) – 0.08 mm (38 AWG) |
| Penetration ability on steel | 39 – 37 mm |
| Spatial resolution, line pairs per mm | 1.0 mm |
| Visible contrast levels, not less | 24 |
| Operator workstation parameters | |
| Monitor | Two 19” LCD monitors
1280 x 1024, 24-bit |
| Image archive | 100.000 images |
| Power supply | |
| Voltage | 220V (±10%), 50 Hz, 10 A max |
| Climatic conditions | |
| Workers: | |
| – ambient temperature | 0° – +40 °С |
| – relative humidity | up to 95%, no condensation |
| During storage: | |
| – ambient temperature | -20° – +60 °С |
| – relative humidity | up to 95%, no condensation |
