X-ray television installation (introscope) Astrophysics “XIS 5335”
The X-ray TV is designed for inspection of small luggage, hand luggage, mail, bags, backpacks. The mobile device can be moved to any area, providing constant control. The device is used at airports, train stations, business centers, shopping centers and other institutions where there is a risk of carrying dangerous metal objects.
Functional Features
The compact AstrophysicsXIS 5335 instrument takes up little space when folded. It can be transported in regular vehicles. The device is designed for inspection of small objects.
Tunnel dimensions:
- width – 53 cm;
- height – 35 cm;
The device can be installed in a room with limited space. The image during inspection is displayed on the built-in screen. The transmission is carried out in color, the transmission spectrum is six colors. This allows the operator to speed up the inspection process and quickly identify scanned items.
The inspection can be carried out continuously, images are transmitted to the monitor in real time.
Performance characteristics (TTX):
| Dimensions | |
| Tunnel size | 533 x 356 mm |
| Overall dimensions, no more | 1313 x 764 x 1225 mm |
| Packaging dimensions | 1448 x 863 x 1650 mm |
| Weight, no more | 345 kg |
| Package weight | 505 kg |
| Conveyor | |
| Maximum distributed load on
conveyor | 165 kg |
| Conveyor height | 729 mm |
| Conveyor belt speed | 0.23 m/s |
| X-ray source | |
| Anode voltage | 90 kV |
| Source current | 0.6 mA |
| Radiation direction | diagonally up |
| Cooling system | oil bath with air (convection)
cooling |
| Film safety | up to ISO 1600 (33 DIN) |
| X-ray receiver | |
| Type | L-shaped array |
| Dual energy technology | availability |
| Gray levels | 4096 |
| Detective ability for copper
wire | 0.08 mm (40 AWG) – 0.10 mm (38 AWG) |
| Penetration ability on steel | 12 – 10 mm |
| Spatial resolution, line pairs per
mm | 1.0 mm |
| Visible contrast levels, not less | 24 |
| Operator workstation parameters | |
| Monitor | LCD monitor 19”
1280 x 1024, 24-bit |
| Image archive | 150,000 images |
| Power supply | |
| Voltage | 220V (±10%), 50 Hz, 10 A max |
| Climatic conditions | |
| Workers: | |
| – ambient temperature | 0° – +40 °С |
| – relative humidity (at + 20 °C) | up to 95%, no condensation |
| During storage: | |
| – ambient temperature | -20° – +60 °С |
| – relative humidity (at + 35 °C) | up to 95%, no condensation |
Delivery methods: delivery to the address, delivery by transport companies. We deliver throughout Russia. Delivery prices are calculated by sales managers. Delivery times are calculated depending on the equipment supplied and the conditions specified in the contract. Payment methods: We accept non-cash payments including VAT.
