X-ray television installation (introscope) Astrophysics “XIS-5878”
X-ray television installation Astrophysics “XIS-5878”
XIS-5878 is an X-ray television installation with a tunnel size of 58.4 cm x 78.3 cm. The lower location of the XIS-5878 conveyor (30 cm from the floor) facilitates loading and unloading of the objects being examined. XIS-5878 can be used at airports, railway and bus stations, in places where inspection of heavy baggage is necessary.
XIS-5878 combines small size and high efficiency: the 180kV generator provides high penetrating power, and the conveyor can handle loads up to 165kg.
All Astrophysics installations are equipped with a continuous condition diagnostics system. This function allows you to monitor and identify faults at an early stage of their manifestation, which increases service life, reduces the cost of operation and possible repairs.
Another distinctive feature of Astrophysics installations is the formation of images of inspected objects in a 6-color format (depending on the atomic number of the substance), which greatly facilitates the operator’s work in identifying hazardous materials.
Performance characteristics (TTX):
| Dimensions | |
| Tunnel size | 584 x 783 mm |
| Overall dimensions, no more | 2524 x 1371 x 1260 mm |
| Packaging dimensions | 1910 x 1473 x 1600 mm |
| Weight, no more | 635 kg |
| Package weight | 900 kg |
| Conveyor | |
| Maximum distributed load on
conveyor | 165 kg |
| Conveyor height | 300 mm |
| Conveyor belt speed | 0.23 m/s |
| X-ray source | |
| Anode voltage | 180 kV (operating 165 kV) |
| Source current | 1.2 mA |
| Radiation direction | horizontally to the side |
| Cooling system | oil bath with air (convection)
cooling |
| Film safety | up to ISO 1600 (33 DIN) |
| X-ray receiver | |
| Type | L-shaped array |
| Dual energy technology | availability |
| Gray levels | 4096 |
| Detective ability for copper
wire | 0.08 mm (40 AWG) – 0.10 mm (38 AWG) |
| Penetration ability on steel | 39 – 37 mm |
| Spatial resolution, line pairs per
mm | 1.0 mm |
| Visible contrast levels, not less | 24 |
| Operator workstation parameters | |
| Monitor | two 19" LCD monitors
1280 x 1024, 24-bit |
| Image archive | 150,000 images |
| Power supply | |
| Voltage | 220V (±10%), 50 Hz, 10 A max |
| Climatic conditions | |
| Workers: | |
| – ambient temperature | 0° – +40 °С |
| – relative humidity | up to 95%, no condensation |
| During storage: | |
| – ambient temperature | -20° – +60 °С |
| – relative humidity | up to 95%, no condensation |
