X-ray television installation (introscope) Astrophysics “XIS-6545”
X-ray television installation Astrophysics «XIS-6545"
XIS-6545 is an X-ray television inspection system with a tunnel size of 65.0 cm x 45.0 cm. The model is designed for the inspection of small and medium-sized objects, characterized by reliability, optimal dimensions and effective detection of threats.
The instrument, with a standard 160 kV generator, provides a cost-effective solution for testing in courthouses, prisons, hospitals and airports.
The XIS-6545 Introscope is the most popular system on sale and the most successful inspection solution in the entire Astrophysics line, thanks to its excellent software capabilities and high throughput.
All Astrophysics systems are equipped with a continuous condition diagnostic system. This function monitors and detects defects at an early stage of their manifestation, which increases service life, reduces the cost of operation and possible repairs.
Another feature of Astrophysics X-ray television installations is the formation of images of inspected objects in a six-color format (depending on the atomic number of the substance), which greatly facilitates the operator’s work in identifying hazardous materials.
Performance characteristics (TTX):
| Dimensions | |
| Tunnel size | 650 x 450 mm |
| Overall dimensions, no more | 1516 x 888 x 1305 mm |
| Packaging dimensions | 2311 x 1020 x 1590 mm |
| Weight, no more | 431 kg |
| Package weight | 600 kg |
| Conveyor | |
| Maximum distributed load on
conveyor | 165 kg |
| Conveyor height | 719 mm |
| Conveyor belt speed | 0.23 m/s |
| X-ray source | |
| Anode voltage | 160 kV (operating 150 kV) |
| Source current | 0.7 mA |
| Radiation direction | diagonally up |
| Cooling system | oil bath with air (convection)
cooling |
| Film safety | up to ISO 1600 (33 DIN) |
| X-ray receiver | |
| Type | L-shaped array |
| Dual energy technology | availability |
| Gray levels | 4096 |
| Detective ability for copper
wire | 0.08 mm (40 AWG) – 0.10 mm (38 AWG) |
| Penetration ability on steel | 39 – 37 mm |
| Spatial resolution, line pairs per
mm | 1.0 mm |
| Visible contrast levels, not less | 24 |
| Operator workstation parameters | |
| Monitor | LCD monitor 19”
1280 x 1024, 24-bit |
| Image archive | 150,000 images |
| Power supply | |
| Voltage | 220V (±10%), 50 Hz, 10 A max |
| Climatic conditions | |
| Workers: | |
| – ambient temperature | 0° – +40 °С |
| – relative humidity | up to 95%, no condensation |
| During storage: | |
| – ambient temperature | -20° – +60 °С |
| – relative humidity | up to 95%, no condensation |
