X-ray television installation (introscope) Astrophysics “XIS 7858”
XIS-7858 is a modern inspection X-ray television installation with tunnel dimensions of 77.8 cm x 58.0 cm. XIS-7858 is designed for inspection of large objects with a minimum size of the installation itself. XIS-7858 can be successfully used in airports, hotels, post offices, transport hubs, etc.
XIS-7858 is equipped with a standard 180kV generator, providing high penetration power and image quality.
The XIS-7858 is an ideal solution for inspecting large objects in confined spaces.
All Astrophysics installations are equipped with a continuous condition diagnostics system. This feature allows you to monitor and identify faults at an early stage of their occurrence, which increases service life, reduces operating costs and
possible repairs.
Another distinctive feature of Astrophysics installations is the formation of images of inspected objects in a 6-color format (depending on the atomic number of the substance), which greatly facilitates the operator’s work in identifying hazardous materials. A large number of options are included in the standard configuration, including Russian-language software and keyboard, 6-color image, real-time diagnostics.
Performance characteristics (TTX):
| Dimensions | |
| Tunnel size | 778 x 580 mm |
| Overall dimensions, no more | 2292 x 1006 x 1400 mm |
| Packaging dimensions | 2438 x 1156 x 1828 mm |
| Weight, no more | 587 kg |
| Package weight | 861 kg |
| Conveyor | |
| Maximum distributed load on
conveyor | 165 kg |
| Conveyor height | 691 mm |
| Conveyor belt speed | 0.23 m/s |
| X-ray source | |
| Anode voltage | 180 kV (operating 165 kV) |
| Source current | 1.2 mA |
| Radiation direction | diagonally up |
| Cooling system | oil bath with air (convection)
cooling |
| Film safety | up to ISO 1600 (33 DIN) |
| X-ray receiver | |
| Type | L-shaped array |
| Dual energy technology | availability |
| Gray levels | 4096 |
| Detective ability for copper
wire | 0.08 mm (40 AWG) – 0.10 mm (38 AWG) |
| Penetration ability on steel | 39 – 37 mm |
| Spatial resolution, line pairs per
mm | 1.0 mm |
| Visible contrast levels, not less | 24 |
| Operator workstation parameters | |
| Monitor | LCD monitor 19”
1280 x 1024, 24-bit |
| Image archive | 150,000 images |
| Power supply | |
| Voltage | 220V (±10%), 50 Hz, 10 A max |
| Climatic conditions | |
| Workers: | |
| – ambient temperature | 0° – +40 °С |
| – relative humidity | up to 95%, no condensation |
| During storage: | |
| – ambient temperature | -20° – +60 °С |
| – relative humidity | up to 95%, no condensation |
